Fiber Laser Marking Machine Machine with CCD automatic visual and positioning system
Fiber Laser Marking Machine for Metal
Rating：
Fiber laser marking machine designed to easy-move equipment, air-cooling, compact machine, Perfect output beam quality, high reliability, no consumables, maintenance-free. Long life Working. Import Germany IPG fiber laser, the international latest, most reliable structure, small size, power consumption is small, no high-voltage without large water-cooled system. Close to the ideal beam, USB interface, output control, optical scanning system, laser repetition rate high, high-speed, without distortion.
Main Feature:
Machine Desciption of CCD Camera Positioning Laser Marking Machine:
The machine has imported high-precision CCD camera positioning and large-scale graphic visual recognition system, which can be integrated with different light sources such as optical fiber, CO2, UV, etc. it can not only automatically locate products for marking and automatic detection of defective products, but also realize large-scale visual positioning and marking through the moving platform.
Features of CCD Camera Positioning Laser Marking Machine
1、automatic intelligent positioning
2、suitable all kinds of metal and nonmetallic material 3、supports automatic loading&unloading system
Machine Configurations:
automatic intelligent positioning It is suitable for flash disk, keyring, and small metal parts.
1.5m length
200mm width
Foot Switch Protect Goggles U disk with software Spanner Keys Screws Ruler Power Cable
Brand Name: Wuhan Raycus Model: 20QB 30QB 50QB Laser Power: 20W 30W 50W Optional Brand: Max./JPT Germany IPG
Brand Name: Beijing Sino Galvo Model: SG2206 high speed scanner
Brand Name: Nanjing Wave Length Mode:SG-1064-112-163G Working Area: 110X110mm
film.
foam
wooden box
20W 30W 50W
20W 30W 50W
Machine Optional Parts:
Diameter: 80mm
Diameter: 50mm
It can be moved left and right, Front and back.
It can be put 24 pcs pens.
It is used for fixing metal sheet when cutting. It will be choosed by 50w 100w big power machine.
It is suitable for 5-120mm diamater cylinder. It can bear within 20Kg cylinder.
Smoke purifier is mainly used for the purification of smoke and dust produced in marking, cutting, and other processes as well as the recovery of rare metals and precious materials
It is used for pen.
Machine Parameters:
|
Type specification |
CS-F20 CS-F30 CS-F50 CS-F100 |
|
Wave length of laser |
1064nm |
|
Laser repetition frequency |
20kHz~100kHz |
|
Laser power |
20W 30W 50W 100W |
|
Marking scope |
70*70mm 110*110 mm 150*150mm 175*175mm 200*200mm 250*250mm 300*300mm optional |
|
Laser sources |
Fiber module |
|
Laser Head |
Scanning head |
|
The minimum focus facula diameter |
20μm |
|
Minimal character |
0.01mm |
|
Marking speed |
≤7000mm/s |
|
Repeated accuracy |
0.0025mm |
|
Cooling ways |
Force-air Cooling |
|
Power supply |
220V/ 50Hz/2kVA |
|
Process Material |
All kinds of metal and part of Non-metal Materials |
|
Support format |
PLT, BMP, DXF, JPG, TIF, AI etc |
|
Package |
Standard Crate for export |
|
Package Size and Gross Weight |
132×102×160cm 200kg |
Video Tutorials & Instructional Video:
Sample Display:
Industry Application:
Electronic Components: Resistors, Capacitors, Chips, Printed Circuit Boards, Keyboard, etc.
Mechanical Parts: Bearings, Gears, Standard Parts, Motor, etc.
Instrument: Panel Board, Nameplates, Precision equipment, Medical Instruments etc.
Hardware Tools: Knives, Tools, Measuring Tools, Cutting Tools, Gold Silver Brass Jewelry etc.
Automobile Parts: Pistons&Rings, Gears, Shafts, Bearings, Clutch, Lights.
Daily Necessities: Handicrafts, Zipper, Key Holder, Sanitary Ware, etc.
Marking Materials:
Fiber laser marking machine could work perfectly for most metal materials. Such as Gold Silver Brass Jewelry, Aluminium, Stainless Steel, Iron Copperetc. And some plastic materials, such as ABS.
Especially 50w and 100w laser marking machine could cut small gold silver brass jewelry within 1mm.
